New Shantui Road Machinery 210HP Big Engine Power Motor Grader SG21-3 FOR SALE ONLINE

$700,000.00

Category:

Description

New Shantui Road Machinery 210HP Big Engine Power Motor Grader SG21-3 FOR SALE ONLINE

motor power grade

Description

Motor power grade

Quick Details
Applicable Industries:
Farms, Construction works , Energy & Mining
Machinery Test Report:
Provided
Marketing Type:
Hot Product 2019
Warranty of core components:
1 Year
Core Components:
Engine, Motor, Pump
Condition:
New
Forward Speed(km/h):
39.7
Reverse Speed(km/h):
25.4
Brand Name:
SHANTUI
Certification:
ISO
After-sales Service Provided:
Video technical support, Online support, Field maintenance and repair service
Warranty:
1 Year
Hydraulic Cylinder Brand:
Huade
Hydraulic Pump Brand:
Kawasaki
Hydraulic Valve Brand:
Kawasaki
Engine Brand:
Cummins
UNIQUE SELLING POINT:
Low Maintenance Cost
Engine model:
6BTAA5.9-C180
Minimum fuel consumption:
206 g/kW.h
Rated power/speed:
132 kW/2200 rpm
Piston displacement:
5.9L
Blade length:
3660/3965 mm
Blade height:
635 mm
Cutting angle adjustment range:
44~91°
Maximum cutting depth:
500 mm
Maximum lift above ground:
440 mm
Max blade lateral extension (left/right):
1900/1950mm

Product Description

The Shantui series paver adopts full hydraulic drive and microcomputer control technology, and is equipped with imported high-precision automatic leveling equipment. It has good stability at low speed and has superior control precision and handling. The core components are all famous foreign brands. Its high stability and long life to improve construction quality and paving efficiency to improve construction quality and paving efficiency; ideal construction equipment for paving roadbeds and pavements
New Shantui Road Machinery 210HP Big Engine Power
Motor Grader SG21-3
Engine
Engine model
Cummins 6BTAA5.9-C180
Rated power/speed
132 kW/2200 rpm
Engine type
In-line, water-cooled, 4-cycle, direct injection, turbocharged
Number of cylinders
6(102X120mm)
Piston displacement
5.9L
Maximum torque/speed
770 N·m/1500 rpm
Minimum fuel consumption
206 g/kW·h
travel speed
Transmission and torque converter: Electronic controlled transmission
Gear
1st
2nd
3rd
4th
5th
6th
Forward
0~5.4 km/h
0~9.3 km/h
0~12.2 km/h
0~20.7km/h
0~25.6 km/h
0~39.7 km/h
Reverse
0~5.4 km/h
0~12.2 km/h
0~25.6 km/h
TRAVEL
Tire Type
17.5-25PR12
Steering system
Max. steering angle of front wheel
±45°
Max. tilting angle of front wheel
±17°
Max. oscillating angle of front axle
±15°
Steering angle of frame
±25°
Max. oscillating angle of rear axle
±15°
Min. turning radius
7800 mm
Operation weight
Operating weight (standard configuration)
16200 kg
Front axle load
4800 kg
Rear axle load
11400 kg
Blade
Blade length
3660/3965 mm
Blade height
635 mm
Blade rotational angle
360°
Cutting angle adjustment range
44~91°
Maximum cutting depth
500 mm
Cutting force per dozing
24.47 kN/m
Maximum lift above ground
440 mm
Maximum blade lateral extension (left/right)
1900/1950 mm
Technical Features
Working Scene
