Long lifetime powerplus motor grader liugong 4230 for road FOR SALE – ONLINE

Name: Long lifetime powerplus motor grader liugong 4230 for road FOR SALE – ONLINE
SKU: 1781
Price: 80000.00 USD
Availability: InStock

Description

Motor grader

Quick Details

Applicable Industries:: Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Construction works , Energy & Mining, Construction works

Machinery Test Report:: Provided

Marketing Type:: Ordinary Product

Warranty of core components:: 1 Year

Core Components:: PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Condition:: New, New

Forward Speed(km/h):: 42

Reverse Speed(km/h):: 26.2

Brand Name:: Liugong

Dimension(L*W*H):: 9265 mm*4272 mm*3500 mm

Certification:: ISO9001:2008 / CE

Warranty:: 1 Year, 1 Year

Hydraulic Cylinder Brand:: imported

Hydraulic Pump Brand:: imported

Hydraulic Valve Brand:: imported

Engine Brand:: imported

UNIQUE SELLING POINT:: Low Maintenance Cost

Working diameter:: 4272 mm, 4272 mm

Maximum travel speed, forward:: 42 km/h

Maximum travel speed, reverse:: 26.2 km/h

Turning radius:: 7300 mm

Articulation angle:: ±20°

Maximum overall height:: 3500 mm

Width over tires:: 2600 mm

Long lifetime powerplus motor grader liugong 4230 for road

Product Description

Fuel Efficient Dongfeng Imported Engine.

Low Vibration, Noise, Dust +UV Resistant cab

Meritor wet axle with “no-spin” differential lock as standard

Balance box enables the 4 rear wheels to swing up and down by +/- 15°

AWD and 4WD

Parameters

Operating weight	16700 kg
Weight on front wheels	5010 kg
Weight on rear tandem	11690 kg
Drawbar pull	91 kN
Emission regulation	Tier 2 / Stage II
Rated power	172 kW (233 hp) @ 2200 rpm
Net power	155 kW (211 hp) @ 2200 rpm
Type	Power shift
Speeds	6f / 3r
Maximum travel speed, forward	42 km/h
Maximum travel speed, reverse	26.2 km/h
Turning radius	7300 mm
Articulation angle	±20°
Maximum overall height	3500 mm
Width over tires	2600 mm
Blade width	4272 mm
Overall length	9265 mm
